Volvo Wheel Loader L45H

Model: L45H

  • Operating Weight8670 kg
  • Horse Power100 hp
  • KW75 kW

Please note: all fields are required to enable your query to be directed to your local TDX expert. Cancel

Contact details:
Your query:
* Please check the "I'm not a robot" box above to continue.
Description

Description - Volvo Wheel Loader L45H

Volvo’s L45H is a compact and well-balanced machine whose solid design gives you the strongest performance in the tightest jobsites. It features Volvo's unique Torque Parallel (TP) linkage for high breakout torque and parallel movement through the entire lifting range. Equipped with a powerful Tier 4 Final / Stage V Volvo engine and an intelligent load-sensing hydrostatic transmission, the L45H matches power to your requirements—providing excellent control for delicate work and full power for more demanding jobs.

Specifications

Specifications - Volvo Wheel Loader L45H

  • Engine: Volvo D4J

  • Engine gross power: 75 kW (100 hp)

  • Engine net power: 73 kW (99.3 hp)

  • Bucket capacity: 1.4 m³

  • Tipping load (ISO/DIS 14397-1 at full turn 40 degree): 5,290 kg

  • Breakout force: 62 kN

  • Hydraulic lifting capacity, max: 74 kN

  • Fork payload 80%: 4,000 kg

  • Operating weight: 8,670 kg

  • Maximum travel speed: 20 km/h (Standard) / up to 50 km/h (High-speed option)
